Experience the ultimate in durability, non‑stick performance, and chemical resistance with our Teflon Coated Glass Fabric: Premium PTFE Fiberglass Coating Solutions. This ptfe fiberglass coating product line from JVC (Jiangsu Vichen Composite Material Co., Ltd.) offers multiple series—Premium, Industrial, Porous, Anti‑Static—tailored for conveyor belts, insulation jackets, food‑grade applications, and aerospace needs. Backed by ISO 9001 certification, custom seam types, rapid turnaround, and global logistics, our PTFE materials ensure your operation runs smoothly under the harshest conditions.
PTFE Coated Fiberglass Fabric is a high-performance composite material manufactured by coating premium fiberglass fabric with PTFE resin. Combining the mechanical strength of fiberglass with the superior non-stick and heat-resistant properties of PTFE, this industrial fabric is widely used in packaging, food processing, conveyor systems, heat sealing equipment, and thermal insulation applications.
Our PTFE coated fiberglass fabrics are engineered for demanding industrial environments requiring excellent dimensional stability, chemical resistance, low friction, and continuous high-temperature performance. With advanced coating technology and strict quality control, we provide durable PTFE fiberglass solutions for global OEM manufacturers, distributors, and industrial processing companies.
JVC's ptfe fiberglass coating combines a high‑strength fiberglass substrate with an advanced PTFE layer, delivering:
● Non‑Stick Excellence: Exceptional release properties for food processing and composite molding. The smooth PTFE coating provides excellent release performance and low friction characteristics, reducing material adhesion and improving production efficiency.
● Chemical Resistance: Outstanding inertness against acids, bases, and solvents. Our PTFE fiberglass fabric resists most industrial chemicals, acids, alkalis, solvents, and corrosive substances, ensuring long-term durability in aggressive environments.
● Thermal Stability: Reliable performance from –70 °C up to +260 °C. PTFE coated fiberglass fabric can operate continuously from -70°C to 260°C, making it ideal for high-temperature industrial processes and thermal applications.
● Mechanical Durability: High tensile strength and tear resistance.
● High Mechanical Strength: The fiberglass substrate offers exceptional tensile strength, dimensional stability, and tear resistance for heavy-duty industrial applications.
● FDA Food Grade Compliance: Selected PTFE coated fiberglass fabrics comply with FDA standards for food processing, baking, packaging, and conveyor applications.
Technical Specifications
| Category | Specifications |
| Thickness & Weight | Thickness: 0.1mm – 1.0mm (customizable) • Weight: 200 – 1000 g/m² |
| Mechanical Strength | Tensile Strength: 100–500 N/cm (warp/weft) • Tear-Resistant (ASTM D258 compliant) |
| Temperature Resistance | -70°C to +260°C (continuous) • Short-term peaks up to 300°C |
| Chemical & Functional | Resists acids, alkalis, solvents • Non-stick • Low friction (coefficient <0.1) |
| Light Transmission | Opaque (standard) • Mesh variants: 10%–50% light transmission |
| Insulation | Dielectric Strength: 5–10 kV/mm • Excellent thermal/electrical insulation |
Key Product Series
A top‑grade ptfe fiberglass coating for critical applications requiring the highest purity white finish—ideal as teflon coated glass fabric for FDA‑compliant baking sheets and release liners.
Cost‑effective, robust ptfe coated glass cloth engineered for heavy‑duty conveyor belts in packaging, automotive, and general manufacturing.
Specialty porous teflon and porous ptfe sheet options allow controlled airflow and moisture release—perfect for dewatering belts and filtration media.
Incorporates conductive additives to dissipate static build‑up, enhancing safety in electronics assembly and powder‑coating lines.
Application Scenarios
● Conveyor Belts PTFE Coated Fiberglass: High‑speed, non‑stick surfaces in food, packaging, and industrial lines.
● Insulation Jackets PTFE Coated Fiberglass: Thermal protection for aerospace, automotive, and HVAC systems.
● Food Industry PTFE Coated Fiberglass: FDA‑approved white PTFE fabric ensures hygienic release and easy cleaning.
● Release Sheets PTFE Coated Fiberglass: Non‑stick liners for composite molding, rubber vulcanization, and adhesive processes.
● Electrical Insulation PTFE Coated Fiberglass: Durable PTFE layers in transformers, cables, and circuit boards.
● High‑Temperature Covers PTFE Coated Fiberglass: Welding blankets and furnace linings withstand extreme heat.
Why Choose Our PTFE Coated Fiberglass
Advanced Coating Technology
We use precision PTFE coating processes to ensure uniform surface quality, excellent adhesion, and stable performance.
OEM & Custom Manufacturing
Custom thickness, width, color, mesh size, and coating solutions are available according to customer requirements.
Strict Quality Control
All products undergo rigorous testing for thickness, tensile strength, coating adhesion, temperature resistance, and dimensional stability.
Global Export Experience
We provide PTFE coated fiberglass fabrics for customers in packaging, food processing, electronics, aerospace, chemical, and industrial manufacturing industries worldwide.
Services & Customization
Seam Types
Bullnose joints
Finger joints
Overlap seams
Coatings & Colors
Single‑ and double‑sided PTFE
Custom color options (e.g., pure white for food safety)
Rapid Turnaround
Extensive stock of standard grades
2–4 week lead time for bespoke orders
Samples & Technical Support
Complimentary sample requests
Expert guidance on material selection and integration
| Feature | PTFE Coated Fiberglass | Silicone Coated Fiberglass |
|---|
| Non-Stick Performance | Excellent | Moderate |
| Chemical Resistance | Excellent | Good |
| Temperature Resistance | Higher | High |
| Friction Coefficient | Very Low | Moderate |
| Food Processing Use | Widely Used | Limited |
| Surface Smoothness | Excellent | Moderate |
Experience unmatched performance and reliability with our ptfe fiberglass coating, perfectly engineered to elevate your industrial and food‑grade applications.
